| Overall width | 74.88" | Auger speed | NA |
| Cutting width | 72" | Horsepower requirement | 45-75 HP |
| Overall length | 44.6" | Net weight | 1020 lbs |
| Overall height | 63.5" | Adjustable chute deflector | Yes |
| Cutting height | 27.65" | Adjustable skid shoes | Yes |
| Number of blades on impeller | 4 | Replaceable cutting edge | Yes |
| Impeller diameter | 24" | Hitch system | Skid steer/loader mounting plate(optional) |
| Impeller housing depth | 7.87" | Whether to match quick change | NA |
| Auger diameter | 17.5" | Side plate thickness | 0.24" |
| Discharge chute diameter | 8.66 " | Hood thickness | 0.16" |
| Chute rotation degrees | 360° (manual/Electric steering drive) | Snow throwing distance | 75' |
| Chute rotation | Manual /Electric steering driven sprocket(optional) | Parameters of electric pushrod | 254-355.6mm /voltage:12V/currents:＜10A |
| Drive and Control System | Hydraulic motors Gearbox drive motor: 126.3cc/r Maximum flow rate (continuous):75L/min Pressure: 3000psi | Electric machine parameter | 90W /voltage:12V/currents:＜10A |
